Astroflame Passive Fire Protection Products

Trade Name: Astro Finger Defender

Finger Defender Hinge Guards

Prevents finger trapping accidents.

Suitable for automatic or manual operation doors.

Suitable for most single or double-action doors.

Extremely durable and maintenance free.

Tested to over 1 million open & closing cycles.

Fits most doors up to 180° opening depending on door configuration.

Satin Anodised Aluminium, Dark Bronze Anodised or White as standard or any RAL colour on request.

Standard length 1925mm with a maximum opening of 260mm.

Longer version 2015mm meets EN16005:2012 for automatic doors.

Tested to EN16654:2015 Child Protection Products.

Tested to BS8613:2017 Finger Protection for Pedestrian Doors.

Astro Finger Defender - in various colours and sizes

View a range of styles



>> See more : Additional product images

>> Call us to order: 01329 844 500

>> Email us to order: sales@astroflame.com

Description

The Astro Finger Defender is a durable, high quality finger guard with discreet styling, suitable for most single and double-action doors, including automated doors. A resilient 'roller blind' style mechanism prevents fingers from entering the cavity formed between the edge of the door and door frame.

The blind fully retracts into the robust aluminium housing when the door is closed - unlike concertina style finger guard blinds that are exposed to impact damage when closed.

Also suitable for use with manually operated (non-automated) doors. This finger guard has concealed screw fixings and comes complete with end caps for that even neater finish.

The aluminium housing is available in three standard finishes and any RAL colour on request. Independently tested to over 1 million opening & closing cycles.

Maximum opening: 260mm.

Finger Guardian Dimensions

Astro Finger Defender (measurements in mm)

Please ask for a sample to view the actual colour and construction of this product: Fill in our enquiry form

Availability

Available in a standard length 1925mm with a maximum opening of 260mm.
Stock finishes: Silver Anodised Finish, White or Dark Bronze.
RAL colour coated versions and non standard lengths available to special order & subject to minimum order size.
The longer version 2015mm size guard complies with EN16005:2012 for automatic doors.

Standard Lengths

Product Code

Description

Size

Colour

AFFDEFSAF

Astro Finger Defender

1925mm

Satin Anodised Aluminium

AFFDEFWHT

Astro Finger Defender

1925mm

White (RAL 9016)

AFFDEFDB

Astro Finger Defender

1925mm

Dark Bronze

AFFDEFCOL

Astro Finger Defender

1925mm

RAL Colours to Order

Longer Lengths

Product Code

Description

Size

Colour

AFFDEFSAFX

Astro Finger Defender - Long

2015mm

Satin Anodised Aluminium

AFFDEFWHTX

Astro Finger Defender - Long

2015mm

White (RAL 9016)

AFFDEFDBX

Astro Finger Defender - Long

2015mm

Dark Bronze

AFFDEFCOLX

Astro Finger Defender - Long

2015mm

RAL Colours to Order

To Order & Specify

Please contact us and quote the following information - Quantity / Product Description / Product Code / Colour / Size Typical wording - 10no / Astro Finger Defender / AFFDEFSAF / Satin Anodised Aluminium / 1925mm

>> Tel: 01329 844 500 or >> Email: sales@astroflame.com

Installation

For further information on installation requirements please see the installation sheet or contact the technical team on: tel 01329 844 500 or email sales@astroflame.com

Health and Safety

The product does not present any known health hazards during or after installation. Normal good industrial and personal hygiene practices should be observed. For further information on health and safety requirements please contact the technical team on: tel 01329 844 500 or email sales@astroflame.com
