Passive Fire Stop Products are a form of fire safety provision that remains dormant, or inert, during normal conditions but becomes active in a fire situation. It is an integral component of structural fire protection in a building, which is designed to contain fire and smoke or slow their spread.

Download Brochure

The purpose is to contain the spread of fire for sufficient time to permit the safe evacuation of all occupants of the premises and the arrival of the fire brigade. Astroflame's Passive Fire Stop Products also serves to ensure the building remains as safe as possible for entry in this situation and to minimise damage to the building itself.

The following Fire Stop products are used to slow the spread of fire via the various penetrations and voids commonly occurring in buildings for pipework, conduits, ducts, cables, socket boxes, ventilation, exterior cladding etc. as required in the UK Building Regulations, Approved Document B - Fire Compartmentation.

For a trade or wholesale price on our Fire Stop product range please get in touch with us or click on the links below to see more information about each Fire Stop product:

tel: 01329 844 500 or email: sales@astroflame.com



Product Details

Trade Name: Astro X Series CE Pipe Collar

Certified fire protection for plastic pipework | Offers EI120 and EI240 tested in accordance with EN1366-3 : 2009 | Fire collars for pipe sizes from 32mm to 250mm | CE Marked Intumescent Pipe Collars.


Product Details

Trade Name: Astro PFP Pipe Closer

CE Marked - Astro PFP Intumescent Pipe Closer are designed to maintain the fire resistance of fire rated walls and floors where these are breached by continuous plastic pipes.


Product Details

Trade Name: Astro X Series CE Pipewrap UL

25 metre roll of material for fabricating intumescent pipe wraps on site | For plastic pipework from 40mm to 200mm diameter | CE and Certifire approved.


Product Details

Trade Name: Astro X Series CE Pipe Wrap

Intumescent pipe wraps for most types of plastic pipes | Sizes 32mm to 200mm diameter | CE Marked | Fire Resistance Testing to EN 1366-3 : 2009.


Product Details

Trade Name: Astro PFP FR Pipe Wrap

Intumescent Pipe Wraps | Certified for PVC-U, PVC-C, PE, LDPE, MDPE, HDPE, ABS, SAN+PVC and PP pipes | Fire classifications up to 240 minutes | 30 years working life guarantee.


Product Details

Trade Name: Astro Thermal
Fire PS

Pipe Fire Sleeves for Plastic and Metal Pipes | Fire Rated BS 476 Part 20 and EN 1366-3 | Easy to Fit | CE Marked | 4-in-1 Solution – Fire, Acoustic, Thermal and Vapour Seal


Product Details

Trade Name: Astro X Series Pillow

Intumescent fire pillows | For temporary (re-useable) or permanent fire protection | Various sizes | Fire Resistance EN 1366-3 | Fire Classification EN13501-2.


Product Details

Trade Name: Astro Pillow

Fire pillows | Certifire Approved | Fire Pillows tested to BS476: Part 20: 1987 | Small size available | Easy to install & re-locate | For wall floor & ceiling penetrations.


Product Details

Trade Name: Astro FR Ceiling Valve

Fire Rated Ceiling Air Valves | Supply and extract valve versions available in 5 sizes | Maintains fire integrity of 60 minute fire rated ceilings.


Product Details

Trade Name: Astro DS
Duct Sleeve

Fire resistant duct sleeve | Fire protection for plastic ventilation ducts | Up to 120 minutes fire rated | Tested in accordance with BS 476 Parts 20 and 22 : 1987and EN 1366-3 : 2009 | Simple to install.


Product Details

Trade Name: Astro DS Low Profile Duct Sleeve

Low profile intumescent duct sleeve for plastic ventilation ducts | Suits wide range of fire partition walls | Easy installation / retrofitting | Up to 120 minutes rating to EN 1366-3 : 2009.


Product Details

Trade Name: Astro PFP FR
Putty Seal

Easy to apply fire & sound rated pad for sockets | Available in a range of sizes | EN 1366-3:2004 & BS:EN 1364-1 fire tested.


Product Details

Trade Name: Astro FRA Socket Box Insert

Fire Rated, Pre-moulded, Electrical Wall Box Inserts | Quicker and easier than putty pads | Fire, Acoustic and Airtightness rated.


Product Details

Trade Name: Astro FRA Socket Box Cover

Easy to install putty pad alternative | Pre-formed covers to fit most electrical switch boxes | BS 476 Fire Tested for 120 Minutes | Single and Double Sockets sizes.


Product Details

Trade Name: Astro Clad Ventilated Fire Barrier

Intumescent Ventilated Fire Barriers | Fire Barrier for External Wall Systems | BS476: Parts 20 and 22, EN1363-1: 1999 | To suit from 25mm up to 450mm cavities | Tested for up to 2 hours.


Product Details

Trade Name: Astro CavGuard
Roll 65

Cavity Fire Barrier | Designed to firestop the cavity behind external walls consisting of outer substrates of masonry or brickwork | Up to 60 mins fire rating | Rolls of 6.3m long.


Product Details

Trade Name: Astro
EJ Seal

Fire stopping material for expansion joints | Fire resistance to EN 1366-4 E 120, EI 120 and BS 476 | Up to 150mm gap size.


Product Details

Trade Name: Astro HS Compound

A High strength fire resistant mortar | For use on rigid floors or walls | High strength and load bearing properties | Easy to mix and for internal use.


Product Details

Trade Name: Astro PFP FR EX Mortar

Fire Stopping Mortar | Suitable for most surfaces, included concrete, bricks, Leca, steel, plastic | Simple to apply leaving a very smooth finish.


Product Details

Trade Name: Astro PFP
FR Boards

Fire Stopping Boards | Consists of a high density stone wool core | Classified for all types of constructions with or without building service penetrations | Easy to install.


Product Details

Trade Name: Astro PFP
FR Coating

Ablative Sealant Coating | Enhance, seal and fire protect mineral fibres | Suitable for most surfaces | Resists water and frost.


Product Details

Trade Name: Astro
Batt

Fire resistant board | Fire Resistance to EN 1366-3 EI 30 EI 60, EI 90, EI 120 BS 476 - 240mins | Life expectancy of over 25 years.


Product Details

Trade Name: Astro Coat
Spray Grade

Astroflame ablative coating for use with fire batt | Fire Resistance Testing to EN 1366-3 : 2009 | CE marked UL-EU listed Certifire Approved | Excellent fire, water, air permeability and elastomeric properties.


Product Details

Trade Name: Astro
PS Coat

Highly advanced flexible coating | apply to uncoated stonewool boards | reinstate the fire resistance performance of wall and floor constructions | CE Marked and UL EU Accreditation.


Product Details

Trade Name: Astro Intu Mastic - Trowel Grade

Astro Intu Mastic - Trowel Grade | Tested with Metallic Pipes, Cables, Cable Bunches, Cable Trays and Cable Ladders | CE, Certifire & UL-EU Listed | Fire resistance tested in flexible walls, rigid walls and floors.


Product Details

Trade Name: Astro
Putty

Fire Reistant Putty | Fully Certified | Highly flexible and water resistant | Fills irregular shapes | Up to 4 hours fire resistance.


Product Details

Trade Name: View all Astroflame Fire Rated Mastic & Foams

Fire Rated Mastic, Silicone, Acrylic & Foams | Simple to apply | Permanently flexible | High end formula, certified worldwide.
